Making awesome Wedding documents using OpenType Ligatures and Stylistic Sets in Microsoft Word 2010 and Gabriola

August 02, 2011 Comment on this post [20] Posted in Tools
Sponsored By

ligaturesmallMy brother-in-law is getting married in a few weeks and  since I'm the default IT guy for the family, I'm making CDs with CD-TEXT for the guests amongst other things. One of those other things is doing the Agenda for the day as well as the Menus that appear on the guests' tables. Anyone can bang out a simple document in word and/or pick a wacky font, but I wanted to try something a little different.

Microsoft Word 2010 includes advanced support for OpenType Fonts, not just TrueType fonts. One of the cool things in OpenType and Word is the support for ligatures. From Wikipedia:

"In writing and typography, a ligature occurs where two or more graphemes are joined as a single glyph."

For example, here's lowercase "fi" and lowercase "fl" first without ligatures, and then with:

The characters fi and fl without ligatures, then with

See how the two letters flow together with ligatures? Here's more examples with words like "office," "afflict," and "fine flavor."

More fi and fl words with ligatures applied

Open Ligatures are really visible (and mind-blowing if you've expected fonts to work a certain way for 20 years like me) in complex scripts like Gabriola, one of the many new fonts that comes with Windows 7. The Gabriola font is filled with advanced Open Type features.

The letterforms will change based on the context of the other letters around them. For example, notice how the second m in the word murmur gets out of the way of the r that would otherwise encroach on its space? It's different from the first m.

The word "murmur" in Gabriola

This is just the default behavior, but with Word 2010 you can control it from the Advanced Tab in the Font Menu. For example, I wanted to create a wedding menu so here's the first few lines with the defaults for Gabriola:


Now, I'll right click on Menu and select Font, then Advanced. There are a number of Stylistic Sets, depending on which font you're using. I liked the look of Set 6.

The Advanced Font Menu in Word 2010

Next,  for the second and third lines I changed to Stylistic Set 5 with Contextual Alternates to give me more options. Compare the two side by side! So much has changed, some subtle, some not. Notice the captial S's, the lowered C, the additions to the L and the tail on the small n and p?

The menu with the default sets The same menu lines with a nicer stylistic set


There's a lot of choices that you can make to get the look you want, and of course, this is just the Gabriola font we've see so far!

Magic Unicorns

The font will even change based on where it appears on a line, for example, the word amazon at the start, middle and end (taken from this article by John Hudson, the font designer):


Amazon in three styles

Additionally, this all happens as you type. You have to see it to believe it. I made an animated GIF at the top for you to get the idea. This might seem very weird to English/Latin speakers, but if you have ever typed in Hindi or Arabic you're already used to dynamic ligatures as you type.

Word 2010 also support different modes for numbering, like Old-Style Number Forms. Notice how the numbers' baselines are different on the second line and their sizes have been adjusted?

1234567 first aligned to the top, then along a baseline. Note the smaller "2"

All very cool stuff just sitting there in Word 2010 for you to use. Enjoy!

All very cool stuff just sitting there in Word 2010 for you to use. Enjoy!
